CMPT2222A TR
RoHS
/
Package /
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
PDF
/
Inventory: 3108
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Surface Mount YES
Number of Terminals 3
Transistor Element Material SILICON
Technical
JESD-609 Code e0
Pbfree Code icon-pbfree no
ECCN Code EAR99
Terminal Finish TIN LEAD
HTS Code 8541.21.00.75
Subcategory Other Transistors
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PDSO-G3
Qualification Status Not Qualified
Operating Temperature (Max) 150°C
Number of Elements 1
Configuration SINGLE
Transistor Application SWITCHING
Polarity/Channel Type NPN
Transition Frequency 300MHz
Power Dissipation-Max (Abs) 0.35W
Collector Current-Max (IC) 0.6A
DC Current Gain-Min (hFE) 100
Collector-Emitter Voltage-Max 40V
VCEsat-Max 1 V
Turn Off Time-Max (toff) 285ns
Turn On Time-Max (ton) 35ns
Collector-Base Capacitance-Max 8pF
Compliance
RoHS Status Non-RoHS Compliant
