2N6055
RoHS
/
Package TO-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
PDF
/
Buying Options
Total Price: USD $44.02
Unit Price: USD $44.0211
≥1 USD $44.0211
≥10 USD $36.11995
≥100 USD $34.99135
≥500 USD $33.86275
≥1000 USD $32.73415
Inventory: 2204
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Through Hole
Package / Case TO-3
Technical
Published 2005
JESD-609 Code e0
Pbfree Code no
Part Status Active
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
Max Operating Temperature 150°C
Min Operating Temperature -65°C
HTS Code 8541.29.00.95
Subcategory Other Transistors
Terminal Position BOTTOM
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 2
JESD-30 Code O-MBFM-P2
Qualification Status Not Qualified
Number of Elements 1
Polarity NPN
Power Dissipation-Max 100W
Element Configuration Single
Power Dissipation 100W
Case Connection COLLECTOR
Transistor Application SWITCHING
Collector Emitter Voltage (VCEO) 3V
Max Collector Current 8A
Collector Emitter Breakdown Voltage 60V
Transition Frequency 4MHz
Frequency - Transition 4MHz
Collector Base Voltage (VCBO) 60V
Emitter Base Voltage (VEBO) 5V
DC Current Gain-Min (hFE) 750
Continuous Collector Current 450mA
Compliance
RoHS Status RoHS Compliant
