2N3905
RoHS
/
Package TO-92
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Bipolar Transistors - BJT PNP Gen Pur SS
PDF
/
Buying Options
Total Price: USD $0.06
Unit Price: USD $0.0616
≥1 USD $0.0616
Inventory: 1838
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mount Through Hole
Package / Case TO-92
Technical
Published 2011
JESD-609 Code e0
Pbfree Code no
Part Status Active
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
Max Operating Temperature 150°C
Min Operating Temperature -55°C
HTS Code 8541.21.00.75
Subcategory Other Transistors
Terminal Position BOTTOM
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 3
JESD-30 Code O-PBCY-T3
Qualification Status Not Qualified
Number of Elements 1
Polarity PNP
Power Dissipation-Max 625mW
Element Configuration Single
Transistor Application SWITCHING
Gain Bandwidth Product 200MHz
Collector Emitter Voltage (VCEO) 40V
Max Collector Current 50nA
Collector Emitter Breakdown Voltage 40V
Transition Frequency 200MHz
Collector Emitter Saturation Voltage 400mV
Frequency - Transition 200MHz
Collector Base Voltage (VCBO) 40V
Emitter Base Voltage (VEBO) 5V
hFE Min 30
DC Current Gain-Min (hFE) 15
Continuous Collector Current 200mA
Turn Off Time-Max (toff) 260ns
Turn On Time-Max (ton) 70ns
Compliance
RoHS Status RoHS Compliant
Lead Free Contains Lead
