2N3708
RoHS
/
Package TO-92
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Trans GP BJT NPN 30V 200mA 3-Pin TO-92 Box
PDF
/
Buying Options
Total Price: USD $2.23
Unit Price: USD $2.2268
≥1 USD $2.2268
≥10 USD $1.82685
≥100 USD $1.76985
≥500 USD $1.71285
≥1000 USD $1.65585
Inventory: 1443
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Continuous Collector Current 200mA
DC Current Gain-Min (hFE) 45
hFE Min 45
Emitter Base Voltage (VEBO) 6V
Collector Base Voltage (VCBO) 30V
Collector Emitter Saturation Voltage 1V
Transition Frequency 100MHz
Collector Emitter Breakdown Voltage 30V
Max Collector Current 100nA
Collector Emitter Voltage (VCEO) 30V
Element Configuration Single
Power Dissipation-Max 625mW
Polarity NPN
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code O-PBCY-T3
Pin Count 3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position BOTTOM
Subcategory Other Transistors
HTS Code 8541.21.00.95
Additional Feature LOW NOISE
Min Operating Temperature -65°C
Max Operating Temperature 150°C
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 3
Part Status Active
Pbfree Code no
JESD-609 Code e0
Published 2015
Packaging Box
Physical
Package / Case TO-92
Mount Through Hole
Supply Chain
Factory Lead Time 8 Weeks
