2N3704
RoHS
/
Package TO-92
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TO-92 Through Hole Single 3 Bipolar (BJT) Transistor 450mA 625mW 100MHz 50V
PDF
/
Buying Options
Total Price: USD $1.98
Unit Price: USD $1.984255
≥1 USD $1.984255
≥10 USD $1.87194
≥100 USD $1.765986
≥500 USD $1.666025
≥1000 USD $1.571717
Inventory: 4483
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Continuous Collector Current 450mA
DC Current Gain-Min (hFE) 100
hFE Min 100
Emitter Base Voltage (VEBO) 5V
Collector Base Voltage (VCBO) 50V
Frequency - Transition 100MHz
Collector Emitter Saturation Voltage 600mV
Transition Frequency 100MHz
Collector Emitter Breakdown Voltage 30V
Max Collector Current 100nA
Collector Emitter Voltage (VCEO) 30V
Gain Bandwidth Product 100MHz
Transistor Application SWITCHING
Element Configuration Single
Power Dissipation-Max 625mW
Polarity NPN
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code O-PBCY-T3
Pin Count 3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position BOTTOM
Subcategory Other Transistors
HTS Code 8541.21.00.95
Min Operating Temperature -65°C
Max Operating Temperature 150°C
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 3
Part Status Active
Pbfree Code no
JESD-609 Code e0
Published 2015
Physical
Package / Case TO-92
Mount Through Hole
Supply Chain
Factory Lead Time 8 Weeks
