START499D
RoHS
RoHS compliant
RoHS compliantPackage TO-243AA
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - RF
Description
RF Bipolar Transistors NPN RF TRANSISTOR 29dBm 14dBgain 900mz
PDF
/
Inventory: 2639
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-243AA
Number of Pins 4
Weight 130.492855mg
Technical
Operating Temperature 150°C TJ
Packaging Tape & Reel (TR)
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Other Transistors
Max Power Dissipation 1.7W
Terminal Form FLAT
Peak Reflow Temperature (Cel) 260
Base Part Number START499
Pin Count 3
JESD-30 Code R-PSSO-F3
Number of Elements 1
Element Configuration Single
Power Dissipation 1.7W
Polarity/Channel Type NPN
Transistor Type NPN
Collector Emitter Voltage (VCEO) 4.5V
Max Collector Current 1A
DC Current Gain (hFE) (Min) @ Ic, Vce 150 @ 160mA 3V
Collector Emitter Breakdown Voltage 4.5V
Gain 13dB ~ 14dB
Max Breakdown Voltage 4.5V
Emitter Base Voltage (VEBO) 1.5V
Continuous Collector Current 1A
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
