MSC3930-BT1
RoHS
/
Package SC-70, SOT-323
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - RF
Description
Tape & Reel (TR) Surface Mount NPN SINGLE RF Transistor 70 @ 1mA 10V 30mA 200mW 150MHz
PDF
/
Buying Options
Total Price: USD $8.47
Unit Price: USD $8.46735
≥1 USD $8.46735
≥10 USD $6.94735
≥100 USD $6.73075
≥500 USD $6.5132
≥1000 USD $6.2966
Inventory: 14407
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Frequency - Transition 150MHz
Transition Frequency 150MHz
Current - Collector (Ic) (Max) 30mA
Voltage - Collector Emitter Breakdown (Max) 20V
DC Current Gain (hFE) (Min) @ Ic, Vce 70 @ 1mA 10V
Transistor Type NPN
Polarity/Channel Type NPN
Transistor Application AMPLIFIER
Power - Max 200mW
Configuration SINGLE
Number of Elements 1
Qualification Status COMMERCIAL
JESD-30 Code R-PDSO-G3
Pin Count 3
Time@Peak Reflow Temperature-Max (s) 30
Peak Reflow Temperature (Cel) 240
Terminal Form GULL WING
Terminal Position DUAL
Terminal Finish TIN LEAD
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Tape & Reel (TR)
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Surface Mount YES
Package / Case SC-70, SOT-323
Mounting Type Surface Mount
