KST5179MTF
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - RF
Description
Tape & Reel (TR) Surface Mount NPN SINGLE RF Transistor 25 @ 3mA 1V 50mA 350mW 15dB
PDF
/
Buying Options
Total Price: USD $0.03
Unit Price: USD $0.0264
≥1 USD $0.0264
Inventory: 47601
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Noise Figure (dB Typ @ f) 4.5dB @ 200MHz
Collector-Base Capacitance-Max 1pF
Highest Frequency Band VERY HIGH FREQUENCY B
Frequency - Transition 900MHz
Transition Frequency 900MHz
Current - Collector (Ic) (Max) 50mA
Voltage - Collector Emitter Breakdown (Max) 12V
Gain 15dB
DC Current Gain (hFE) (Min) @ Ic, Vce 25 @ 3mA 1V
Transistor Type NPN
Polarity/Channel Type NPN
Transistor Application AMPLIFIER
Power - Max 350mW
Configuration SINGLE
Number of Elements 1
Qualification Status COMMERCIAL
JESD-30 Code R-PDSO-G3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Terminal Finish MATTE TIN
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Surface Mount YES
Package / Case TO-236-3, SC-59, SOT-23-3
Mounting Type Surface Mount
