KSC1393YBU
RoHS
RoHS compliant
RoHS compliantPackage TO-226-3, TO-92-3 (TO-226AA)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - RF
Description
Bulk Through Hole NPN SINGLE RF Transistor 90 @ 2mA 10V 20mA 250mW 20dB-24dB
PDF
/
Buying Options
Total Price: USD $0.03
Unit Price: USD $0.0264
≥1 USD $0.0264
Inventory: 878352
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Surface Mount NO
Transistor Element Material SILICON
Technical
Operating Temperature 150°C TJ
Packaging Bulk
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Terminal Finish MATTE TIN
Additional Feature LOW NOISE
Terminal Position BOTTOM
Peak Reflow Temperature (Cel) NOT APPLICABLE
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT APPLICABLE
Pin Count 3
JESD-30 Code O-PBCY-T3
Qualification Status COMMERCIAL
Number of Elements 1
Configuration SINGLE
Power - Max 250mW
Transistor Application AMPLIFIER
Polarity/Channel Type NPN
Transistor Type NPN
DC Current Gain (hFE) (Min) @ Ic, Vce 90 @ 2mA 10V
Gain 20dB ~ 24dB
Voltage - Collector Emitter Breakdown (Max) 30V
Current - Collector (Ic) (Max) 20mA
Transition Frequency 700MHz
Frequency - Transition 700MHz
Highest Frequency Band VERY HIGH FREQUENCY B
Collector-Base Capacitance-Max 0.5pF
Noise Figure (dB Typ @ f) 2dB ~ 3dB @ 200MHz
Compliance
RoHS Status ROHS3 Compliant
