DMC506E20R
RoHS
RoHS compliant
RoHS compliantPackage 6-TSSOP, SC-88, SOT-363
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - RF
Description
Bipolar Transistors - BJT Composite Transistor SC-113DB/SOT-363
PDF
/
Inventory: 5394
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Noise Figure (dB Typ @ f) 3.3dB @ 100MHz
Highest Frequency Band VERY HIGH FREQUENCY B
Emitter Base Voltage (VEBO) 3V
Collector Base Voltage (VCBO) 30V
Transition Frequency 650MHz
Current - Collector (Ic) (Max) 15mA
Gain 24dB
Collector Emitter Breakdown Voltage 20V
DC Current Gain (hFE) (Min) @ Ic, Vce 65 @ 1mA 6V
Max Collector Current 15mA
Collector Emitter Voltage (VCEO) 20V
Transistor Type 2 NPN (Dual)
Gain Bandwidth Product 650MHz
Transistor Application AMPLIFIER
Element Configuration Dual
Polarity NPN
Number of Elements 2
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form FLAT
Max Power Dissipation 150mW
Subcategory Other Transistors
HTS Code 8541.21.00.75
Max Operating Temperature 150°C
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
Packaging Tape & Reel (TR)
Physical
Transistor Element Material SILICON
Number of Pins 6
Package / Case 6-TSSOP, SC-88, SOT-363
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
