MAPRST0912-350
RoHS
RoHS compliant
RoHS compliantPackage Ceramic
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - RF
Description
RF TRANS NPN 65V 1.215GHZ
PDF
/
Buying Options
Total Price: USD $1622.08
Unit Price: USD $1622.077447
≥1 USD $1622.077447
≥200 USD $647.220313
≥500 USD $625.591598
≥1000 USD $614.905905
Inventory: 1086
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 28 Weeks
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Package / Case Ceramic
Transistor Element Material SILICON
Technical
Operating Temperature 200°C TJ
Packaging Tray
Published 2009
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Additional Feature WITH EMITTER BALLASTING RESISTORS
Max Power Dissipation 350W
Terminal Position DUAL
Terminal Form FLAT
Peak Reflow Temperature (Cel) NOT SPECIFIED
Frequency 1.215GHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 2
JESD-30 Code R-CDFM-F2
Qualification Status Not Qualified
Number of Elements 1
Element Configuration Single
Case Connection BASE
Transistor Application AMPLIFIER
Polarity/Channel Type NPN
Transistor Type NPN
Collector Emitter Voltage (VCEO) 65V
Max Collector Current 32.5A
Collector Emitter Breakdown Voltage 65V
Gain 9.4dB
Emitter Base Voltage (VEBO) 3V
Continuous Collector Current 32.5A
Compliance
RoHS Status ROHS3 Compliant
