BFP183WH6327XTSA1
RoHS
RoHS compliant
RoHS compliantPackage SC-82A, SOT-343
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - RF
Description
TRANS RF NPN 12V SOT343
PDF
/
Buying Options
Total Price: USD $0.23
Unit Price: USD $0.2288
≥1 USD $0.2288
≥10 USD $0.18392
≥100 USD $0.168256
≥500 USD $0.125136
≥1000 USD $0.113414
≥3000 USD $0.093878
Inventory: 1234
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 1.25mm
Length 2mm
Height 900μm
Technical
Noise Figure (dB Typ @ f) 0.9dB ~ 1.4dB @ 900MHz ~ 1.8GHz
Emitter Base Voltage (VEBO) 2V
Collector Base Voltage (VCBO) 20V
Frequency - Transition 8.5GHz
Max Breakdown Voltage 12V
Transition Frequency 8000MHz
Gain 22dB
Collector Emitter Breakdown Voltage 12V
DC Current Gain (hFE) (Min) @ Ic, Vce 70 @ 15mA 8V
Max Collector Current 65mA
Collector Emitter Voltage (VCEO) 12V
Transistor Type NPN
Polarity/Channel Type NPN
Halogen Free Halogen Free
Transistor Application AMPLIFIER
Power Dissipation 450mW
Element Configuration Single
Number of Elements 1
Base Part Number BFP183
Frequency 8GHz
Terminal Form GULL WING
Terminal Position DUAL
Max Power Dissipation 450mW
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2014
Packaging Tape & Reel (TR)
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 4
Package / Case SC-82A, SOT-343
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Factory Lead Time 4 Weeks
