BFP 620F E7764
RoHS
RoHS compliant
RoHS compliantPackage 4-SMD, Flat Leads
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - RF
Description
RF TRANS NPN 2.8V 65GHZ 4TSFP
PDF
/
Inventory: 6873
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Noise Figure (dB Typ @ f) 0.7dB ~ 1.3dB @ 1.8GHz ~ 6GHz
Collector-Base Capacitance-Max 0.2pF
Highest Frequency Band C B
Frequency - Transition 65GHz
Transition Frequency 65000MHz
Current - Collector (Ic) (Max) 80mA
Voltage - Collector Emitter Breakdown (Max) 2.8V
Gain 21dB
DC Current Gain (hFE) (Min) @ Ic, Vce 110 @ 50mA 1.5V
Transistor Type NPN
Polarity/Channel Type NPN
Power - Max 185mW
Configuration SINGLE
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-PDSO-F4
Pin Count 4
Base Part Number BFP620
Time@Peak Reflow Temperature-Max (s) 40
Reach Compliance Code compliant
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Additional Feature LOW NOISE, HIGH RELIABILITY
Terminal Finish MATTE TIN
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON GERMANIUM
Surface Mount YES
Package / Case 4-SMD, Flat Leads
Mounting Type Surface Mount
