HCT700TXV
RoHS
/
Package 6-SMD, No Lead
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Arrays
Description
Tray Surface Mount NPN AND PNP SEPARATE 2ELEMENTS Bipolar (BJT) Transistor Array 75 @ 1mA 10V 800mA 600mA 400mW 60V
PDF
/
Inventory: 4331
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Current - Collector (Ic) (Max) 800mA 600mA
Voltage - Collector Emitter Breakdown (Max) 50V 60V
Collector Emitter Breakdown Voltage 60V
Vce Saturation (Max) @ Ib, Ic 1V @ 50mA, 500mA
Current - Collector Cutoff (Max) 10nA ICBO
DC Current Gain (hFE) (Min) @ Ic, Vce 75 @ 1mA 10V
Max Collector Current 600mA
Collector Emitter Voltage (VCEO) 1V
Transistor Type NPN, PNP
Polarity/Channel Type NPN AND PNP
Configuration SEPARATE, 2 ELEMENTS
Number of Elements 2
Qualification Status Not Qualified
JESD-30 Code R-CDSO-N6
Reference Standard MIL
Terminal Position DUAL
Max Power Dissipation 400mW
HTS Code 8541.21.00.95
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 2001
Packaging Tray
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case 6-SMD, No Lead
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 25 Weeks
