ULN2004ANSR
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.209, 5.30mm Width)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Arrays
Description
Automotive AEC-Q100 Tape & Reel (TR) Surface Mount 7NPN Darlington Bipolar (BJT) Transistor Array 1.6V @ 500muA 350mA 50muA 50V -20C~70C TA
PDF
/
Buying Options
Total Price: USD $0.51
Unit Price: USD $0.5104
≥1 USD $0.5104
≥10 USD $0.4488
≥100 USD $0.421696
≥500 USD $0.34408
≥1000 USD $0.319616
≥3000 USD $0.272008
Inventory: 1095
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1.95mm
Width 5.3mm
Length 10.3mm
Height 2mm
Technical
Max Breakdown Voltage 50V
Collector Emitter Saturation Voltage 1.1V
Collector Emitter Breakdown Voltage 50V
Vce Saturation (Max) @ Ib, Ic 1.6V @ 500μA, 350mA
Current - Collector Cutoff (Max) 50μA
Max Collector Current 500mA
Collector Emitter Voltage (VCEO) 50V
Transistor Type 7 NPN Darlington
Transistor Application SWITCHING
Configuration COMPLEX
Polarity NPN
Number of Elements 7
Pin Count 16
Base Part Number ULN2004
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
HTS Code 8541.29.00.95
Additional Feature LOGIC LEVEL COMPATIBLE
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series Automotive, AEC-Q100
Packaging Tape & Reel (TR)
Operating Temperature -20°C~70°C TA
Physical
Transistor Element Material SILICON
Weight 200.686274mg
Number of Pins 16
Package / Case 16-SOIC (0.209, 5.30mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 6 Weeks
