ULN2003ADE4
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Arrays
Description
Automotive AEC-Q100 Tube Surface Mount 7NPN Darlington Bipolar (BJT) Transistor Array 1.6V @ 500muA 350mA 50muA 50V -20C~70C TA
PDF
/
Buying Options
Total Price: USD $0.1
Unit Price: USD $0.09975
≥1 USD $0.09975
≥10 USD $0.0817
≥100 USD $0.0798
≥500 USD $0.07695
≥1000 USD $0.0741
≥10000 USD $0.0665
Inventory: 167008
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-SOIC (0.154, 3.90mm Width)
Number of Pins 16
Weight 141.690917mg
Transistor Element Material SILICON
Technical
Operating Temperature -20°C~70°C TA
Packaging Tube
Series Automotive, AEC-Q100
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Additional Feature LOGIC LEVEL COMPATIBLE
HTS Code 8541.29.00.95
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Base Part Number ULN2003
Pin Count 16
Max Output Current 500mA
Number of Elements 7
Polarity NPN
Configuration COMPLEX
Max Output Voltage 50V
Transistor Application SWITCHING
Max Input Voltage 5V
Transistor Type 7 NPN Darlington
Collector Emitter Voltage (VCEO) 50V
Max Collector Current 500mA
Current - Collector Cutoff (Max) 50μA
JEDEC-95 Code MS-012AC
Vce Saturation (Max) @ Ib, Ic 1.6V @ 500μA, 350mA
Collector Emitter Breakdown Voltage 50V
Collector Emitter Saturation Voltage 1.1V
VCEsat-Max 1.6 V
Dimensions
Height 1.75mm
Length 9.9mm
Width 3.91mm
Thickness 1.58mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
