L6221CD013TR
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.295, 7.50mm Width)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Arrays
Description
TRANS 4NPN DARL 60V 1.2A 20SOIC
PDF
/
Inventory: 8335
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 7.5mm
Length 12.8mm
Height Seated (Max) 2.65mm
Technical
Output Current Flow Direction SINK
Continuous Collector Current 1.8A
Turn Off Time 5 μs
Output Peak Current Limit-Nom 2.2A
Interface IC Type AND GATE BASED PERIPHERAL DRIVER
Current - Collector (Ic) (Max) 1.2A
Voltage - Collector Emitter Breakdown (Max) 60V
Transistor Type 4 NPN Darlington (Quad)
Power Dissipation 3.5W
Nominal Supply Current 20mA
Supply Voltage-Max (Vsup) 5.5V
Number of Outputs 4
Pin Count 20
Base Part Number L6221
Terminal Pitch 1.27mm
Supply Voltage 5V
Number of Functions 4
Terminal Form GULL WING
Terminal Position DUAL
Max Power Dissipation 3.5W
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Packaging Tape & Reel (TR)
Operating Temperature -40°C~150°C TJ
Physical
Number of Pins 20
Package / Case 20-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
