Category Switches / Toggle Switches
Description
Toggle Switches SP ON-OFF-ON LUG
PDF
/
Inventory: 5576
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Mounting Type Panel Mount
Surface Mount NO
Technical
Packaging Bulk
Published 2004
Series MTF Green
JESD-609 Code e4
Part Status Active
ECCN Code EAR99
Terminal Finish Gold (Au)
HTS Code 8536.50.90.65
Termination Style Solder Lug
Body Length or Diameter 13mm
Operating Temperature (Max) 80°C
Body Breadth 8 mm
Actuator Type Flatted
Operating Temperature (Min) -20°C
Circuit SPDT
Switch Function On-Off-On
Contact Current(DC)-Max 4A
Sealing EPOXY TERMINAL SEALED
Contact Voltage(DC)-Max 28V
Electrical Life 60000 Cycle(s)
Illumination Non-Illuminated
Switch Type TOGGLE SWITCH
Bushing Thread 1/4-40
Contact Current(AC)-Max 6A
Contact (AC) Max Rating R Load 6A@125VAC
Contact (DC) Max Rating R Load 4A@28VDC
Contact Voltage(AC)-Max 125V
Operating Force-Max 14.71 N
Dimensions
Body Height 10mm
Actuator Length 12.32mm
Compliance
RoHS Status RoHS Compliant
