A201SYCB
RoHS
/
Package /
Category Switches / Toggle Switches
Description
Toggle Switches DP ON-ON LNG BAT PCB
PDF
/
Inventory: 4593
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Moisture Sensitivity Level (MSL) Not Applicable
Termination PC Pin
Max Operating Temperature 85°C
Min Operating Temperature -20°C
Part Status Obsolete
Feature Epoxy Sealed Terminals
Series Gemini A
Published 2004
Packaging Bulk
Operating Temperature -20°C~85°C
Bushing Thread 1/4-40
Illumination Type Non-Illuminated
Max Voltage Rating (DC) 20V
Illumination Non-Illuminated
Throw Configuration DPDT
Electrical Life 6,000 Cycles
Max Voltage Rating (AC) 20V
ELV Non-Compliant
Panel Cutout Dimensions Circular - 6.35mm Dia
Switch Function On-On
Circuit DPDT
Actuator Type Standard Round
Voltage - Rated AC 20V
Termination Style PC Pin
Current Rating 5A
Orientation Straight
Current Rating (Amps) 0.4VA AC/DC
Voltage - Rated DC 20V
Power Rating 400mW
Physical
Mounting Type Panel Mount
Mount Through Hole
Contact Plating Gold
Contact Material Silver
Supply Chain
Factory Lead Time 8 Weeks
Compliance
Lead Free Contains Lead
Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Dimensions
Actuator Length 10.41mm
