1571925-3
RoHS
/
Package 125
Category Switches / Toggle Switches
Description
Switch Toggle ON None ON SPDT Flat Toggle Wire Lug 6A 250VAC 28VDC Panel Mount with Threads
PDF
/
Inventory: 9329
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Gold, Silver
Mount Panel
Mounting Type Panel Mount
Package / Case 125
Actuator Material Copper Alloy, Chrome Plated
Technical
Operating Temperature -20°C~80°C
Packaging Bulk
Published 2004
Series MTF Green
Feature Epoxy Sealed Terminals
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Termination Lug
Max Operating Temperature 80°C
Min Operating Temperature -20°C
Voltage - Rated DC 28V
Current Rating (Amps) 6A AC 4A DC
Orientation Straight
Current Rating 4A
Termination Style Solder Lug
Voltage - Rated AC 125V
Actuator Type Flatted
Circuit SPDT
Switch Function On-On
Panel Cutout Dimensions Circular - 6.40mm Dia
Contact Resistance 20mOhm
Max Voltage Rating (AC) 250V
Electrical Life 80,000 Cycles
Throw Configuration SPDT
Illumination Non-Illuminated
Max Voltage Rating (DC) 28V
Mechanical Life 150000 cycles
Illumination Type Non-Illuminated
Bushing Thread 1/4-40
Dimensions
Actuator Length 12.32mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
