1571920-4
RoHS
/
Package /
Category Switches / Toggle Switches
Description
Switch Toggle ON None ON SPDT Long Bat Toggle PC Pins 6A 250VAC 28VDC PC Mount with Threads
PDF
/
Inventory: 6822
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Actuator Length 10.49mm
Body Height 13.26mm
Technical
Operating Force-Max 14.71 N
Contact (DC) Max Rating R Load 4A@28VDC
Contact (AC) Max Rating R Load 6A@125VAC
Contact Current(AC)-Max 6A
Bushing Thread 1/4-40
Switch Type TOGGLE SWITCH
Mechanical Life 150000 cycles
Max Voltage Rating (DC) 28V
Illumination Non-Illuminated
Electrical Life 80,000 Cycles
Max Voltage Rating (AC) 250V
Sealing EPOXY TERMINAL SEALED
Contact Current(DC)-Max 4A
Contact Resistance 20mOhm
Panel Cutout Dimensions Circular - 6.40mm Dia
Switch Function On-On
Circuit SPDT
Actuator Type Standard Round
Body Breadth 13.08 mm
Body Length or Diameter 17.6mm
Voltage - Rated AC 125V
Termination Style PC Pin
Current Rating 4A
Reach Compliance Code unknown
Orientation Straight
Current Rating (Amps) 6A AC 4A DC
Voltage - Rated DC 28V
Terminal Finish GOLD (5)
Termination PC Pin
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Feature Epoxy Sealed Terminals
JESD-609 Code e4
Series MTA Green
Published 2004
Packaging Bulk
Operating Temperature -20°C~80°C
Physical
Actuator Material Copper Alloy, Chrome Plated
Mounting Type Panel Mount
Mount Panel
Contact Material Gold, Silver
Supply Chain
Factory Lead Time 7 Weeks
