S831/328

NKK Switches
RoHS
RoHS RoHS compliant
Package /
Category Switches / Toggle Switches
Description SWITCH TOGGLE 3PST 30A 125V
PDF
/
Inventory: 8197
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Actuator Length 22.00mm

Technical

Bushing Thread M12 x 1
Illumination Type Non-Illuminated
Illumination Non-Illuminated
Throw Configuration 3PST
Electrical Life 25,000 Cycles
Panel Cutout Dimensions Circular - 12.50mm Dia
Switch Function On-Off
Circuit 3PST
Actuator Type Standard Round
Voltage - Rated AC 125V
Termination Style Screw Terminal
Current Rating 30A
Current Rating (Amps) 30A AC/DC
Voltage - Rated DC 30V
Min Operating Temperature -30°C
Max Operating Temperature 70°C
Termination Screw
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Low Temperature Lubricant
Series S
Published 2015
Packaging Bulk
Operating Temperature -30°C~70°C

Physical

Actuator Material Brass, Chrome Plated
Mounting Type Panel Mount
Mount Panel
