S823D/CUL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
Switch,toggle;DPDT;On Off On;15A 125VAC;M12 bshg;Screw term;Flat lvr;CUL mrkd
PDF
/
Buying Options
Total Price: USD $31.33
Unit Price: USD $31.328
≥1 USD $31.328
≥10 USD $28.51112
≥100 USD $27.18496
≥500 USD $25.361424
≥1000 USD $24.366936
≥3000 USD $22.70928
Inventory: 101
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Panel
Mounting Type Panel Mount
Actuator Material Brass, Chrome Plated
Technical
Operating Temperature -10°C~70°C
Packaging Bulk
Published 2015
Series S
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screw
Voltage - Rated DC 30V
Current Rating (Amps) 30A DC
Current Rating 30A
Termination Style Screw Terminal
Body Length or Diameter 42.0116mm
Body Breadth 24.003 mm
Actuator Type Flatted
Circuit DPDT
Switch Function On-Off-On
Panel Cutout Dimensions Circular - 12.50mm Dia
Contact Resistance 0.01mOhm
Insulation Resistance 1000000000Ohm
Dielectric Withstanding Voltage 2000VAC V
Electrical Life 10,000 Cycles
Illumination Non-Illuminated
Bushing Thread M12 x 1
Contact (AC) Max Rating R Load 30A@250VAC
Contact (DC) Max Rating R Load 30A@30VDC
Contact Voltage(AC)-Max 250V
Bushing Length 0.472 inch
Bushing Type M12P1
Dimensions
Body Height 34.0106mm
Actuator Length 27.00mm
Compliance
RoHS Status ROHS3 Compliant
