S1B
RoHS
/
Package /
Category Switches / Toggle Switches
Description
NKK SWITCHES S1BSWITCH, TOGGLE, SPST, 10A, 125VAC
PDF
/
Buying Options
Total Price: USD $0.3
Unit Price: USD $0.2992
≥1 USD $0.2992
≥10 USD $0.20416
≥100 USD $0.099704
≥500 USD $0.083178
≥1000 USD $0.057798
≥3000 USD $0.05009
Inventory: 3052
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Actuator Length 17.50mm
Length 30mm
Technical
Bushing Thread M12 x 1
Illumination Type Non-Illuminated
Contact Current Rating 10A
Max Voltage Rating (DC) 30V
Illumination Non-Illuminated
Throw Configuration SPST
Electrical Life 25,000 Cycles
Max Current Rating 10A
Max Voltage Rating (AC) 250V
Panel Cutout Dimensions Circular - 12.50mm Dia
Switch Function On-Off
Circuit SPST
Actuator Type Standard Round
Voltage - Rated AC 125V
Termination Style Solder Lug
Current Rating 5A
Depth 18mm
Current Rating (Amps) 5A AC/DC
Voltage - Rated DC 30V
Min Operating Temperature -10°C
Max Operating Temperature 70°C
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series S
Published 2012
Packaging Bulk
Operating Temperature -10°C~70°C
Physical
Actuator Material Brass, Chrome Plated
Mounting Type Panel Mount
Mount Panel
Contact Plating Tin
Contact Material Copper
