S114
RoHS
RoHS compliant
RoHS compliantPackage 125
Category Switches / Toggle Switches
Description
SWITCH TOGGLE DPST 5A 125V
PDF
/
Inventory: 6252
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Actuator Length 18.00mm
Length 27.8mm
Technical
Bushing Thread M12 x 1
Illumination Type Illuminated, Non-Illuminated
Contact Current Rating 5A
Max Voltage Rating (DC) 30V
Illumination Non-Illuminated
Electrical Life 10,000 Cycles
Max Current Rating 5A
Max Voltage Rating (AC) 250V
Panel Cutout Dimensions Circular - 12.50mm Dia
Switch Function On-Off
Circuit DPST
Actuator Type Standard Round
Voltage - Rated AC 125V
Termination Style Solder Lug
Current Rating 5A
Depth 17.6mm
Current Rating (Amps) 5A AC/DC
Voltage - Rated DC 30V
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Series S
Packaging Bulk
Operating Temperature -10°C~70°C
Physical
Actuator Material Brass, Chrome Plated
Package / Case 125
Mounting Type Panel Mount
Mount Panel
Contact Material Silver
