M2015SD3G01
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
SWITCH TOGGLE SPDT 0.4VA 28V
PDF
/
Buying Options
Total Price: USD $6.24
Unit Price: USD $6.239461
≥1 USD $6.239461
≥10 USD $5.886287
≥100 USD $5.553101
≥500 USD $5.238774
≥1000 USD $4.94224
Inventory: 2655
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Contact Material Gold
Mount Panel
Mounting Type Panel Mount
Actuator Material Brass, Chrome Plated
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2006
Series M
Feature Epoxy Sealed Terminals
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Power Rating 400mW
Voltage - Rated DC 28V
Current Rating (Amps) 0.4VA AC/DC
Orientation Vertical
Ingress Protection IP67 - Dust Tight, Waterproof
Current Rating 100mA
Termination Style Solder Lug
Voltage - Rated AC 28V
Actuator Type Standard Round
Circuit SPDT
Switch Function On-Mom
Panel Cutout Dimensions Circular - 6.50mm Dia
Electrical Life 50,000 Cycles
Illumination Non-Illuminated
Switch Type TOGGLE SWITCH
Bushing Thread 1/4-40
Dimensions
Actuator Length 10.50mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Ratings Dust Tight, IP67, Waterproof
