M2012ES2G40

NKK Switches
RoHS
/
Package /
Category Switches / Toggle Switches
Description Toggle Switches SPDT ON-NONE-ON
PDF
/
Inventory: 6720
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Contact Plating Gold
Mount Through Hole, Vertical
Mounting Type Through Hole, Right Angle, Vertical
Actuator Material Brass, Chrome Plated

Technical

Operating Temperature -30°C~85°C
Packaging Bulk
Published 2001
Series M
Feature Epoxy Sealed Terminals
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Power Rating 400mW
Voltage - Rated DC 28V
Current Rating (Amps) 0.4VA AC/DC
Orientation Vertical
Current Rating 100mA
Termination Style PC Pin
Voltage - Rated AC 28V
Actuator Type Flatted
Circuit SPDT
Switch Function On-On
Electrical Life 50,000 Cycles
Illumination Non-Illuminated
Switch Type TOGGLE SWITCH
Bushing Thread Unthreaded

Dimensions

Length 13mm
Width 7.9mm
Actuator Length 11.40mm

Compliance

RoHS Status RoHS Compliant
Lead Free Contains Lead
