E2018
RoHS
/
Package /
Category Switches / Toggle Switches
Description
SWITCH TOGGLE SPDT 3A 125V
PDF
/
Inventory: 6256
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Actuator Length 10.50mm
Length - Termination 0.157 inch
Body Height 31.7754mm
Technical
Bushing Type M6P0.75
Bushing Length 0.283 inch
Contact Function (ON)-OFF-(ON)
Contact (AC) Max Rating R Load 3A@125VAC
Contact Current(AC)-Max 3A
Bushing Thread M6 x 0.75
Illumination Non-Illuminated
Electrical Life 20,000 Cycles
Dielectric Withstanding Voltage 1500VAC V
Insulation Resistance 1000000000Ohm
Contact Resistance 0.01mOhm
Panel Cutout Dimensions Circular - 6.50mm Dia
Switch Function Mom-Off-Mom
Circuit SPDT
Actuator Type Standard Round
Body Breadth 7.0104 mm
Body Length or Diameter 10.9982mm
Voltage - Rated AC 125V
Termination Style Solder Lug
Current Rating 3A
Orientation Vertical
Current Rating (Amps) 3A AC
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Series E
Published 2005
Packaging Bulk
Operating Temperature -10°C~70°C
Physical
Actuator Material Brass, Chrome Plated
Mounting Type Panel Mount
Mount Panel
Contact Plating Silver
