D22015LH
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
Locking Lever D2 Through Hole Right Angle Bulk Toggle Switch 19.40mm 0.4VA AC/DC 1500VAC V 0.4VA@48VAC
PDF
/
Inventory: 8762
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 19.40mm
Length - Termination 0.138 inch
Body Height 15.24mm
Technical
Contact (AC) Max Power Rating R Load 0.4VA@48VAC
Bushing Length 0.26 inch
Contact Function ON-(ON)
PCB Hole Count 5
Contact Timing BREAK-BEFORE-MAKE
Bushing Thread Unthreaded
Switch Type TOGGLE SWITCH
Illumination Non-Illuminated
Electrical Life 50,000 Cycles
Dielectric Withstanding Voltage 1500VAC V
Insulation Resistance 1000000000Ohm
Contact Resistance 0.05mOhm
Switch Function On-Mom
Circuit SPDT
Actuator Type Locking Lever
Body Breadth 7.3152 mm
Body Length or Diameter 14.7066mm
Voltage - Rated AC 48V
Termination Style PC Pin
Current Rating (Amps) 0.4VA AC/DC
Voltage - Rated DC 48V
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series D2
Published 2015
Packaging Bulk
Operating Temperature -10°C~70°C
Physical
End Contact Plating GOLD
Center Contact Material PHOSPHOR BRONZE
Center Contact Plating GOLD
Actuator Material Brass, Chrome Plated
Housing Material POLYBUTYLENE TEREPHTHALATE
Insulation Material GLASS FILLED POLYAMIDE
Mounting Type Through Hole, Right Angle
Mount Through Hole
Supply Chain
Factory Lead Time 8 Weeks
