A22HB image
Favorite
A22HB image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Switches / Toggle Switches
Description Flatted A 2 Through Hole Toggle Switch 6.30mm 100mA 28V 0.05mOhm
PDF
/
Buying Options
Total Price: USD $6.52
Unit Price: USD $6.5208
≥1 USD $6.5208
≥10 USD $5.87224
≥100 USD $5.577088
≥500 USD $5.34094
≥1000 USD $5.163954
≥3000 USD $4.898344
Inventory: 152
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 5 Weeks

Physical

Contact Material Brass
Contact Plating Gold
Mount Through Hole
Mounting Type Through Hole
Housing Material Polyamide
Actuator Material Brass, Nickel Plated

Technical

Operating Temperature -30°C~85°C
Packaging Tray
Published 2010
Series A
JESD-609 Code e4
Feature Process Sealed
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Power Rating 400mW
Voltage - Rated DC 28V
Current Rating (Amps) 0.4VA AC/DC
Orientation Vertical
Current Rating 100mA
Termination Style PC Pin
Voltage - Rated AC 28V
Body Length or Diameter 9.8044mm
Body Breadth 9.4996 mm
Actuator Type Flatted
Circuit DPDT
Switch Function On-On
Contact Resistance 0.05mOhm
Insulation Resistance 500000000Ohm
Sealing EPOXY
Electrical Life 50,000 Cycles
Number of Poles 2
Illumination Non-Illuminated
Switch Type TOGGLE SWITCH
Bushing Thread Unthreaded, Square
PCB Hole Count 10
Bushing Length 0.138 inch
Life (Cycles) 50000 cycles
Washability SOLVENT

Dimensions

Actuator Length 6.30mm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Contains Lead
