AML23GBE2CA01
RoHS
/
Package /
Category Switches / Toggle Switches
Description
Illuminated LED Lamp AML23 Panel Mount Snap-In Bulk Toggle Switch 28.85mm 2A 24VAC
PDF
/
Inventory: 5347
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Contact Material Silver
Mount Panel, Snap in
Mounting Type Panel Mount, Snap-In
Technical
Packaging Bulk
Published 2001
Series AML23
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Voltage - Rated DC 24V
Current Rating (Amps) 3A AC 2A DC
Orientation Straight
Reach Compliance Code unknown
Current Rating 2A
Termination Style Solder, Quick Connect - 0.110 (2.8mm)
Voltage - Rated AC 125V
Body Length or Diameter 28.85mm
Body Breadth 18.92 mm
Actuator Type Paddle
Circuit DPDT
Switch Function On-On
Panel Cutout Dimensions Rectangular - 28.98mm x 19.05mm
Contact Current(DC)-Max 2A
Illumination Voltage (Nominal) 24VAC
Illumination Type, Color Incandescent
Electrical Life 25,000 Cycles
Illumination Illuminated
Switch Type TOGGLE SWITCH
Illumination Type Illuminated, LED, Lamp
Dimensions
Body Height 36mm
Compliance
RoHS Status RoHS Compliant
