RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
Toggle Switches Sealed OI/AT TOG SW ASSEM
PDF
/
Buying Options
Total Price: USD $2240.38
Unit Price: USD $2240.383763
≥1 USD $2240.383763
≥200 USD $893.928665
≥500 USD $864.056251
≥1000 USD $849.296629
Inventory: 9705
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Actuator Length 29.97mm
Body Height 27.94mm
Technical
Operating Force-Max 22.24 N
Contact Voltage(AC)-Max 115V
Contact (DC) Max Rating R Load 7A@28VDC
Contact Current(AC)-Max 7A
Bushing Thread 15/32-32
Illumination Type Illuminated
Switch Type TOGGLE SWITCH
Illumination Non-Illuminated
Electrical Life 6,000 Cycles
Sealing CORROSION PROOF
Contact Current(DC)-Max 7A
Panel Cutout Dimensions Circular - 12.40mm Dia
Switch Function On-On
Circuit 6PDT
Actuator Type Locking Lever
Body Breadth 23.62 mm
Body Length or Diameter 27.94mm
Voltage - Rated AC 115V
Termination Style Solder Turret
Current Rating 7A
Reach Compliance Code unknown
Current Rating (Amps) 7A AC/DC
Voltage - Rated DC 28V
HTS Code 8536.50.90.65
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series AT
Published 1998
Packaging Bulk
Operating Temperature -55°C~85°C
Physical
Mounting Type Panel Mount
Mount Bushing
Supply Chain
Factory Lead Time 23 Weeks
Alternative Model
