RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
SWITCH TOGGLE 4PDT 15A 125V
PDF
/
Buying Options
Total Price: USD $81.73
Unit Price: USD $81.7344
≥1 USD $81.7344
≥10 USD $74.47
≥100 USD $69.475296
≥500 USD $66.750992
≥1000 USD $62.210016
Inventory: 128
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Material Cadmium, Silver
Mount Bushing
Mounting Type Panel Mount
Number of Pins 2
Technical
Operating Temperature -40°C~71°C
Packaging Bulk
Published 2001
Series NT
Feature Sealed
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Quick Connect
ECCN Code EAR99
HTS Code 8536.50.90.65
Current Rating (Amps) 15A AC
Orientation Straight
Ingress Protection IP67/68 - Dust Tight, Waterproof
Depth 41.6mm
Current Rating 15A
Termination Style Quick Connect - 0.250 (6.3mm)
Voltage - Rated AC 125V
Actuator Type Standard Round
Circuit 4PDT
Switch Function On-On
Panel Cutout Dimensions Circular - 12.40mm Dia
Sealing IP67; IP68
Max Voltage Rating (AC) 277V
Max Current Rating 20A
Illumination Non-Illuminated
Max Voltage Rating (DC) 250V
Switch Type TOGGLE SWITCH
Contact Current Rating 15A
Illumination Type Illuminated, Non-Illuminated
Bushing Thread 15/32-32
Dimensions
Length 33.4mm
Body Height 34.4mm
Actuator Length 17.27mm
Compliance
REACH SVHC Unknown
RoHS Status RoHS Compliant
Ratings Dust Tight, IP67, Waterproof
