34CMSP11B8V2RT
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
SWITCH TOGGLE SPDT 0.4VA 20V
PDF
/
Inventory: 9492
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Contact Plating Gold
Mount Brackets, Through Hole
Mounting Type Through Hole
Actuator Material Brass, Chrome Plated
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2010
Series 34C
JESD-609 Code e4
Feature Epoxy Sealed Terminals
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
ECCN Code EAR99
HTS Code 8536.50.90.65
Voltage - Rated DC 20V
Current Rating (Amps) 0.4VA AC/DC
Termination Style PC Pin
Voltage - Rated AC 20V
Body Length or Diameter 10.16mm
Body Breadth 5.08 mm
Actuator Type Standard Round
Circuit SPDT
Switch Function On-On
Contact Current(DC)-Max 0.02A
Sealing EPOXY TERMINAL SEALED
Electrical Life 30,000 Cycles
Illumination Non-Illuminated
Max Voltage Rating (DC) 20V
Switch Type TOGGLE SWITCH
Bushing Thread Unthreaded
Contact Current(AC)-Max 0.02A
Contact (AC) Max Rating R Load .02A@20VAC
Contact (DC) Max Rating R Load .02A@20VDC
Dimensions
Body Height 9.02mm
Actuator Length 8.38mm
Compliance
RoHS Status RoHS Compliant
