34ASP12B1M6QT
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
Switch Toggle ON None ON SPDT Round Toggle PC Pins 5A 250VAC 28VDC PC Mount with Bracket and Threads
PDF
/
Inventory: 1763
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Actuator Length 5.08mm
Length - Termination 0.125 inch
Body Height 12.7mm
Technical
Bushing Length 0.35 inch
PCB Hole Count 5
Contact (DC) Max Rating R Load 5A@28VDC
Contact (AC) Max Rating R Load 2A@250VAC
Contact Current(AC)-Max 2A
Bushing Thread 1/4-40
Switch Type TOGGLE SWITCH
Max Voltage Rating (DC) 28V
Illumination Non-Illuminated
Electrical Life 40,000 Cycles
Dielectric Withstanding Voltage 1400VAC V
Max Voltage Rating (AC) 250V
Sealing EPOXY
Contact Current(DC)-Max 5A
Insulation Resistance 1000000000Ohm
Contact Resistance 0.01mOhm
Panel Cutout Dimensions Circular - 6.35mm Dia
Switch Function On-On
Circuit SPDT
Actuator Type Standard Round
Body Breadth 6.858 mm
Body Length or Diameter 12.7mm
Voltage - Rated AC 125V
Termination Style PC Pin
Current Rating 5A
Current Rating (Amps) 5A AC/DC
Voltage - Rated DC 28V
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series 34A
Published 2011
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
End Contact Material COPPER ALLOY
Center Contact Material COPPER ALLOY
Actuator Material Brass, Chrome Plated
Housing Material STAINLESS STEEL
Insulation Material DIALLYL PHTHALATE
Mounting Type Panel Mount, Right Angle
Mount Brackets, Panel
Contact Plating Silver
Supply Chain
Factory Lead Time 18 Weeks
