34A4P11B3M2RT
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
Switch Toggle ON None ON 4PDT Round Toggle PC Pins 20VAC 20VDC 0.4VA PC Mount with Threads
PDF
/
Inventory: 8052
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Actuator Length 12.19mm
Length - Termination 0.25 inch
Body Height 10.541mm
Technical
Contact (DC) Max Power Rating R Load 0.4VA@20VDC
Bushing Length 0.28 inch
Bushing Thread 1/4-40
Switch Type TOGGLE SWITCH
Max Voltage Rating (DC) 20V
Illumination Non-Illuminated
Electrical Life 40,000 Cycles
Dielectric Withstanding Voltage 1400VAC V
Sealing EPOXY
Insulation Resistance 1000000000Ohm
Contact Resistance 0.01mOhm
Panel Cutout Dimensions Circular - 6.35mm Dia
Switch Function On-On
Circuit 4PDT
Actuator Type Standard Round
Body Breadth 12.7 mm
Body Length or Diameter 21.59mm
Voltage - Rated AC 20V
Termination Style PC Pin
Current Rating (Amps) 0.4VA AC/DC
Voltage - Rated DC 20V
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series 34A
Published 2011
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
End Contact Material COPPER ALLOY
Center Contact Material COPPER ALLOY
Actuator Material Brass, Chrome Plated
Housing Material STAINLESS STEEL
Insulation Material DIALLYL PHTHALATE
Mounting Type Panel Mount
Mount Panel
Contact Plating Gold
Supply Chain
Factory Lead Time 18 Weeks
