A327S1YZQ
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
Switch, Toggle;Mini;3PDT;(On)-Off-(On);.41 Bat Lever;.35 Thread;6A;125VAC;Solder
PDF
/
Inventory: 3079
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Silver
Contact Plating Silver
Mount Panel
Mounting Type Panel Mount
Body Material Phenolic
Actuator Material Brass, Chrome Plated
Technical
Operating Temperature -30°C~90°C
Packaging Bulk
Published 2001
Series A
Feature Epoxy Sealed Terminals
Part Status Active
Termination Solder
Number of Positions 3
Max Operating Temperature 90°C
Min Operating Temperature -30°C
Voltage - Rated DC 28V
Current Rating (Amps) 6A AC/DC
Current Rating 6A
Termination Style Solder Lug
Voltage - Rated AC 125V
Approval Agency CSA, UL
Actuator Type Standard Round
Circuit 3PDT
Switch Function Mom-Off-Mom
Insulation Resistance 1GOhm
Electrical Life 60,000 Cycles
Number of Poles 3
Throw Configuration 3PDT
Illumination Non-Illuminated
Contact Current Rating 6A
Illumination Type Non-Illuminated
Bushing Thread 1/4-40
Dimensions
Actuator Length 10.41mm
Compliance
REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Lead Free
