A223T1TXZQ
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
SWITCH TOGGLE DPDT 6A 125V
PDF
/
Inventory: 4778
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Panel
Mounting Type Panel Mount
Actuator Material Brass, Chrome Plated
Technical
Operating Temperature -30°C~90°C
Packaging Bulk
Series A
Feature Epoxy Sealed Terminals
Part Status Active
Termination Solder
Max Operating Temperature 90°C
Min Operating Temperature -30°C
Voltage - Rated DC 28V
Current Rating (Amps) 6A AC/DC
Ingress Protection Splash Proof
Current Rating 6A
Termination Style Solder Lug
Voltage - Rated AC 125V
Actuator Type Standard Round
Circuit DPDT
Switch Function On-On
Electrical Life 60,000 Cycles
Throw Configuration DPDT
Illumination Non-Illuminated
Illumination Type Non-Illuminated
Bushing Thread 15/32-32
Dimensions
Actuator Length 17.45mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
