A223S2YAQ
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
Standard Round A Panel Mount Right Angle Bulk Toggle Switch 10.41mm 6A 125V -30C~90C
PDF
/
Inventory: 3240
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Panel
Mounting Type Panel Mount, Right Angle
Actuator Material Brass, Chrome Plated
Technical
Operating Temperature -30°C~90°C
Packaging Bulk
Series A
Feature Epoxy Sealed Terminals
Part Status Active
Termination PC Pin
Max Operating Temperature 90°C
Min Operating Temperature -30°C
Voltage - Rated DC 28V
Current Rating (Amps) 6A AC/DC
Current Rating 6A
Termination Style PC Pin
Voltage - Rated AC 125V
Actuator Type Standard Round
Circuit DPDT
Switch Function On-On
Electrical Life 60,000 Cycles
Throw Configuration DPDT
Illumination Non-Illuminated
Illumination Type Non-Illuminated
Bushing Thread 1/4-40
Dimensions
Actuator Length 10.41mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
