A221T11TXZQ
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
Standard Round A Panel Mount Bulk Toggle Switch 11.89mm 6A AC/DC 28V -30C~90C
PDF
/
Inventory: 7853
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Actuator Length 11.89mm
Technical
Bushing Thread 15/32-32
Illumination Type Non-Illuminated
Illumination Non-Illuminated
Throw Configuration DPDT
Electrical Life 60,000 Cycles
Switch Function On-Off-On
Circuit DPDT
Actuator Type Standard Round
Voltage - Rated AC 125V
Termination Style Solder Lug
Current Rating 6A
Ingress Protection Splash Proof
Current Rating (Amps) 6A AC/DC
Voltage - Rated DC 28V
Min Operating Temperature -30°C
Max Operating Temperature 90°C
Termination Solder
Part Status Active
Feature Epoxy Sealed Terminals
Series A
Packaging Bulk
Operating Temperature -30°C~90°C
Physical
Actuator Material Brass, Chrome Plated
Mounting Type Panel Mount
Mount Panel
