200MSP1T1B7M2QEH
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
SWITCH TOGGLE SPDT 3A 120V
PDF
/
Buying Options
Total Price: USD $6.33
Unit Price: USD $6.326865
≥1 USD $6.326865
≥135 USD $2.524707
≥540 USD $2.440681
≥945 USD $2.398668
Inventory: 1722
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 9.40mm
Length - Termination 0.13 inch
Body Height 8.636mm
Technical
Bushing Length 0.26 inch
PCB Hole Count 3
Contact Voltage(AC)-Max 250V
Contact (AC) Max Rating R Load 1A@250VAC
Contact Current(AC)-Max 1A
Bushing Thread 1/4-40
Switch Type TOGGLE SWITCH
Illumination Non-Illuminated
Electrical Life 30,000 Cycles
Dielectric Withstanding Voltage 1000VRMS V
Contact Voltage(DC)-Max 28V
Contact Current(DC)-Max 3A
Insulation Resistance 1000000000Ohm
Contact Resistance 0.01mOhm
Panel Cutout Dimensions Circular - 6.35mm Dia
Switch Function On-On
Circuit SPDT
Actuator Type Standard Round
Body Breadth 5.08 mm
Body Length or Diameter 8.128mm
Voltage - Rated AC 120V
Termination Style PC Pin
Current Rating (Amps) 3A AC/DC
Voltage - Rated DC 28V
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
Series 200
Published 2008
Packaging Tray
Operating Temperature -30°C~85°C
Physical
End Contact Plating SILVER
End Contact Material COPPER ALLOY
Terminal Material COPPER ALLOY
Center Contact Material COPPER ALLOY
Center Contact Plating SILVER
Actuator Material Brass, Chrome Plated
Housing Material STAINLESS STEEL
Mounting Feature THROUGH HOLE-STRAIGHT
Surface Mount NO
Mounting Type Panel Mount
Supply Chain
Factory Lead Time 8 Weeks
