200MDP1T3B4M7QE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
SWITCH TOGGLE DPDT 3A 120V
PDF
/
Inventory: 2523
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 7.37mm
Length - Termination 0.13 inch
Body Height 14.1732mm
Technical
Bushing Length 0.22 inch
PCB Hole Count 7
Contact Voltage(AC)-Max 250V
Contact (AC) Max Rating R Load 1A@250VAC
Contact Current(AC)-Max 1A
Bushing Thread Unthreaded
Switch Type TOGGLE SWITCH
Illumination Non-Illuminated
Electrical Life 30,000 Cycles
Dielectric Withstanding Voltage 1000VRMS V
Contact Voltage(DC)-Max 28V
Contact Current(DC)-Max 3A
Insulation Resistance 1000000000Ohm
Contact Resistance 0.02mOhm
Switch Function On-On
Circuit DPDT
Actuator Type Standard Round
Body Breadth 8.128 mm
Body Length or Diameter 9.144mm
Voltage - Rated AC 120V
Termination Style PC Pin
Current Rating (Amps) 3A AC/DC
Voltage - Rated DC 28V
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
Series 200
Published 2008
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
End Contact Plating SILVER
End Contact Material COPPER ALLOY
Terminal Material COPPER ALLOY
Center Contact Material COPPER ALLOY
Center Contact Plating SILVER
Actuator Material Brass, Chrome Plated
Housing Material STAINLESS STEEL
Mounting Feature THROUGH HOLE-RIGHT ANGLE
Surface Mount NO
Mounting Type Through Hole, Right Angle, Vertical
Supply Chain
Factory Lead Time 9 Weeks
