200MDP1T2B4M2QE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
SWITCH TOGGLE DPDT 3A 120V
PDF
/
Inventory: 9990
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Plating Silver
Mount Through Hole
Mounting Type Through Hole
Housing Material STAINLESS STEEL
Actuator Material Brass, Chrome Plated
Center Contact Material COPPER ALLOY
Terminal Material COPPER ALLOY
End Contact Material COPPER ALLOY
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Series 200
Feature Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
ECCN Code EAR99
Voltage - Rated DC 28V
Current Rating (Amps) 3A AC/DC
Current Rating 3A
Termination Style PC Pin
Voltage - Rated AC 120V
Body Length or Diameter 9.144mm
Body Breadth 8.128 mm
Actuator Type Standard Round
Circuit DPDT
Switch Function On-On
Contact Resistance 0.02mOhm
Insulation Resistance 1000000000Ohm
Contact Current(DC)-Max 3A
Dielectric Withstanding Voltage 1000VRMS V
Electrical Life 30,000 Cycles
Illumination Non-Illuminated
Switch Type TOGGLE SWITCH
Bushing Thread Unthreaded
Contact Current(AC)-Max 1A
Contact (AC) Max Rating R Load 1A@250VAC
Contact Voltage(AC)-Max 250V
PCB Hole Count 6
Bushing Length 0.22 inch
Dimensions
Body Height 8.636mm
Length - Termination 0.13 inch
Actuator Length 5.33mm
Compliance
RoHS Status ROHS3 Compliant
