GTB-4B18
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
Standard Round GTB Panel Mount Bulk Toggle Switch 16.20mm 12A 250V 1HP@250VAC
PDF
/
Buying Options
Total Price: USD $14.63
Unit Price: USD $14.626384
≥1 USD $14.626384
≥10 USD $13.798481
≥100 USD $13.017432
≥500 USD $12.280595
≥1000 USD $11.585463
Inventory: 1130
Minimum: 1
-
+
Technical Details
Compliance
Ratings Dust Tight, IP68, Waterproof
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 16.20mm
Length - Termination 0.425 inch
Body Height 24.9936mm
Technical
Contact (AC) Max Power Rating R Load 1HP@250VAC
Life (Cycles) 30000 cycles
Bushing Length 0.48 inch
Contact Function (ON)-ON
Contact Voltage(AC)-Max 250V
Contact (AC) Max Rating R Load 12A@250VAC
Bushing Thread 15/32-32
Switch Type TOGGLE SWITCH
Illumination Non-Illuminated
Electrical Life 30,000 Cycles
Dielectric Withstanding Voltage 1500VAC V
Insulation Resistance 100000000Ohm
Contact Resistance 0.02mOhm
Panel Cutout Dimensions Circular - 12.00mm Dia
Switch Function On-Mom
Circuit DPDT
Actuator Type Standard Round
Body Breadth 22.4028 mm
Body Length or Diameter 33.5026mm
Voltage - Rated AC 125V
Termination Style Quick Connect - 0.250 (6.3mm)
Current Rating 12A
Ingress Protection IP68 - Dust Tight, Waterproof
Current Rating (Amps) 12A AC
Voltage - Rated DC 500V
Termination Quick Connect
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series GTB
Published 2012
Packaging Bulk
Physical
Actuator Material Brass, Nickel Plated
Mounting Type Panel Mount
Mount Bushing, Panel
Supply Chain
Factory Lead Time 14 Weeks
