LT1560-741-012
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
SWITCH TOGGLE SPDT 15A 125V
PDF
/
Inventory: 4301
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Panel
Mounting Type Panel Mount
Technical
Operating Temperature 0°C~85°C
Packaging Bulk
Bushing Thread 15/32-32
Switch Type TOGGLE SWITCH
Illumination Illuminated
Electrical Life 50,000 Cycles
Illumination Type, Color Incandescent, Blue/Red
Illumination Voltage (Nominal) 12VAC
Panel Cutout Dimensions Circular - 12.70mm Dia
Switch Function On-Off-On
Circuit SPDT
Actuator Type Standard Round
Voltage - Rated AC 125V
Termination Style Solder Lug
Current Rating 15A
Current Rating (Amps) 15A AC/DC
Voltage - Rated DC 28V
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Sealed
Series LT
Published 2012
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 18.16mm
