U21K12ZQE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
Switch Toggle ON None ON DPDT Locking Lever Solder Lug 5A 250VAC 28VDC Panel Mount with Threads
PDF
/
Inventory: 3762
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Material Silver
Contact Plating Silver
Mount Panel
Mounting Type Panel Mount
Housing Material Stainless Steel
Actuator Material Aluminum
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2012
Series 7000
Feature Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Voltage - Rated DC 28V
Current Rating (Amps) 5A AC/DC
Orientation Straight
Current Rating 5A
Termination Style Solder Lug
Voltage - Rated AC 120V
Actuator Type Locking Lever
Circuit DPDT
Switch Function On-On
Panel Cutout Dimensions Circular - 6.35mm Dia
Max Voltage Rating (AC) 250V
Electrical Life 100,000 Cycles
Throw Configuration DPDT
Illumination Non-Illuminated
Max Voltage Rating (DC) 28V
Illumination Type Non-Illuminated
Bushing Thread 1/4-40
Dimensions
Actuator Length 18.59mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
