U13P3Y3CGE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
Switch Toggle ON OFF ON SPDT Flat Lever PC Pins 5A 250VAC 28VDC 0.4VA PC Mount with Threads
PDF
/
Inventory: 7664
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Plating Gold
Mount Bushing, Panel
Mounting Type Panel Mount
Housing Material Stainless Steel
Actuator Material Brass, Chrome Plated
Contact Material Silver
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2016
Series 7000
Feature Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Voltage - Rated DC 28V
Current Rating (Amps) 5A AC/DC
Depth 6.86mm
Current Rating 5A
Termination Style PC Pin
Voltage - Rated AC 120V
Actuator Type Flat Anti-Rotation
Circuit SPDT
Switch Function On-Off-On
Panel Cutout Dimensions Circular - 6.50mm Dia
Max Voltage Rating (AC) 250V
Max Current Rating 5A
Electrical Life 40,000 Cycles
Throw Configuration SPDT
Illumination Non-Illuminated
Max Voltage Rating (DC) 28V
Illumination Type Non-Illuminated
Bushing Thread M6 x 0.75
Supply Chain
Factory Lead Time 14 Weeks
Dimensions
Length 12.7mm
Actuator Length 11.43mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
