T211STKCQE

C&K
RoHS
RoHS RoHS compliant
Package /
Category Switches / Toggle Switches
Description SWITCH TOGGLE SP3T 2A 120V
PDF
/
Inventory: 7163
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 16 Weeks

Physical

Contact Material Silver
Contact Plating Silver
Mount Panel
Mounting Type Panel Mount
Housing Material Stainless Steel
Actuator Material Brass, Chrome Plated

Technical

Operating Temperature -30°C~85°C
Packaging Bulk
Published 2003
Series T
Feature Jumper needed to achieve triple throw
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Voltage - Rated DC 28V
Current Rating (Amps) 2A AC/DC
Orientation Straight
Current Rating 2A
Termination Style PC Pin
Voltage - Rated AC 120V
Actuator Type Standard Round
Circuit SP3T
Switch Function On-On-On
Panel Cutout Dimensions Circular - 6.35mm Dia
Max Voltage Rating (AC) 120V
Electrical Life 30,000 Cycles
Throw Configuration DPDT, SP3T
Illumination Non-Illuminated
Max Voltage Rating (DC) 28V
Illumination Type Non-Illuminated
Bushing Thread 1/4-40

Dimensions

Actuator Length 7.11mm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
