T211SH9V3GE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
Switch Toggle ON ON ON DPDT Round Lever PC Pins 2A 120VAC 28VDC 0.4VA PC Mount with Bracket
PDF
/
Inventory: 2592
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Silver
Contact Plating Gold
Mount Brackets, Through Hole
Mounting Type Through Hole
Housing Material Stainless Steel
Actuator Material Brass, Chrome Plated
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2014
Series T
Feature Jumper needed to achieve triple throw
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Voltage - Rated DC 28V
Current Rating (Amps) 2A AC/DC
Orientation Straight
Depth 9.14mm
Current Rating 2A
Termination Style PC Pin
Voltage - Rated AC 120V
Actuator Type Standard Round
Circuit SP3T
Switch Function On-On-On
Max Voltage Rating (AC) 120V
Max Current Rating 2A
Electrical Life 30,000 Cycles
Throw Configuration DPDT, SP3T
Illumination Non-Illuminated
Max Voltage Rating (DC) 28V
Illumination Type Non-Illuminated
Bushing Thread Unthreaded
Dimensions
Length 10.57mm
Actuator Length 9.40mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
