T211LHAVPE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
Standard Round T Panel Mount Right Angle Vertical Bulk Toggle Switch 7.37mm 2A 20V -30C~85C
PDF
/
Inventory: 3650
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Plating Gold
Mount Brackets, Panel, Vertical
Mounting Type Panel Mount, Right Angle, Vertical
Housing Material Stainless Steel
Actuator Material Brass, Chrome Plated
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2016
Series T
Feature Jumper needed to achieve triple throw
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Voltage - Rated DC 20V
Current Rating (Amps) 0.4VA AC/DC
Depth 27.24mm
Current Rating 2A
Termination Style PC Pin
Voltage - Rated AC 20V
Actuator Type Standard Round
Circuit SP3T
Switch Function On-On-On
Panel Cutout Dimensions Circular - 4.95mm Dia
Max Voltage Rating (AC) 20V
Electrical Life 30,000 Cycles
Throw Configuration DPDT, SP3T
Illumination Non-Illuminated
Max Voltage Rating (DC) 20V
Illumination Type Non-Illuminated
Bushing Thread 10-48
Dimensions
Length 9.14mm
Actuator Length 7.37mm
Compliance
RoHS Status ROHS3 Compliant
